Monitor Audio C3M Creator Series In-Ceiling Speaker – Single

Elevate Your Sound with Premium In-Ceiling Audio

Introducing the Monitor Audio C3M, the medium-sized Tier 3 in-ceiling loudspeaker that represents the pinnacle of high-performance audio. This three-way model features cutting-edge components, including an RDT III bass driver, IDC II midrange driver, and IDC II tweeter with UD Waveguide II, all engineered to deliver pristine sound quality with incredible detail and transparency. With a convenient cut-out dimension of just 212 mm, the C3M offers quick and simple installation through the patented Quik-Link speaker cable connector and advanced Tri-Grip II system, ensuring a robust and secure fit every time.

This high-performance speaker is designed for installations where only the best acoustics will do, providing a level of sound quality typically found in Monitor Audio's premium loudspeaker ranges. The combination of the RDT III bass driver, IDC II midrange driver, and IDC II tweeter ensures unparalleled transparency and sound clarity, creating a truly immersive listening experience.

Key Features

• Three-Way Design:

  • 1 x 1" (25 mm) IDC II tweeter with UD Waveguide II for clear, lifelike high frequencies.
  • 1 x 4" (102 mm) IDC II midrange driver for accurate mid-range performance.
  • 1 x 7" (178 mm) RDT III bass driver for deep, powerful bass.

• Mid-Frequency ‘Mid-Pod Array’:

  • Engineered to deliver exceptional midrange clarity and dynamic response, setting the speaker apart for premium installations.

• Patented Quik-Link Speaker Cable Connector:

  • Designed for quicker installation, reducing setup time and providing a reliable connection.

• Tri-Grip II System:

  • Ensures a secure and easy fitment for quick and reliable mounting, making the C3M suitable for a wide range of ceiling installations.

• Acoustic Transparency:

  • With advanced acoustic technologies derived from Monitor Audio’s premium loudspeakers, the C3M offers an exceptional level of detail and transparency.

Technical Specifications

• Frequency Range: 45 Hz – 35 kHz

• Compatible Amplifier Power: 45 – 180 W RMS

• Nominal Impedance: 6 ohms

• Sensitivity: 87 dB

• Maximum SPL: 116 dB

• Drivers:

  • 1 x 178 mm (7") RDT III bass driver
  • 1 x 102 mm (4") IDC II midrange driver
  • 1 x 25 mm (1") IDC II tweeter

• Enclosure Type: Open

• Power Type: Passive

• Weight: 3.4 kg

Dimensions

• Cutout Diameter: 212 mm
• Mounting Depth: 148 mm
• Overall Depth: 151 mm
• Overall Diameter: 242 mm

Why Choose the C3M?

The Monitor Audio C3M is designed for installations that demand superior sound performance in a compact in-ceiling speaker. The advanced driver array, coupled with premium acoustic technology, ensures exceptional sound clarity and depth, while the quick and secure installation features make it an ideal choice for high-end home cinema or stereo music systems. Elevate your ceiling audio experience with the C3M, where cutting-edge technology meets exceptional sound quality.

Upgrade your sound system with Monitor Audio’s commitment to excellence in audio engineering.
